About Straight Shanks with Tang

Steel straight shanks with a tang and a threaded end for Severance threaded tools. The Glenzer Sleeves (2, 3 and 4 M.T., EDP 36210 to 36212, listed with the Heavy Duty Countersinks) are used with Severance Heavy Duty Countersinks and straight tanged shanks.

Specialized cutting tools for unique applications.

Ordering Tip

All tools are ordered by their EDP Number (Electronic Data Processing). Find your tool in the table below and use the EDP number when placing orders with your distributor.

Straight Shanks with Tang

Quick Facts

  • 11 products in this group
  • Made in Saginaw, Michigan
  • Precision ground to exacting tolerances
  • Available through authorized distributors
  • Steel construction
Download Full Catalog (PDF)

Available Products

All EDP numbers listed below. Request a quote for any EDP, or find a stocking distributor.

Straight Shanks with Tang

Thread Size Shank Dia. Thread Length Shank Length Shoulder Dia. Tang Length Tang Thickness Tool Name EDP Number
1/4"-281/4"1/4"1-3/4"3/8"5/16".122TX-434135
1/4"-2813/32"1/4"1-3/4"13/32"7/16".242TZ-334136
5/16"-241/4"5/16"1-3/4"7/16"5/16".122TX-1434137
5/16"-2413/32"5/16"1-3/4"7/16"7/16".242TZ-1334138
3/8"-241/4"3/8"1-3/4"1/2"5/16".122TX-2434139
3/8"-2413/32"3/8"1-3/4"1/2"7/16".242TZ-2334140
1/2"-2013/32"1/2"1-3/4"5/8"7/16".242TZ-3334141
1/2"-209/16"1/2"1-3/4"5/8"1/2".303TH-3334142
5/8"-1813/32"5/8"1-3/4"7/8"7/16".242TZ-4334143
5/8"-189/16"5/8"1-3/4"3/4"1/2".303TH-4334144
3/4"-169/16"5/8"1-3/4"7/8"1/2".303TH-5334145
